REP PR-4000 6 Post Pro Rack with Ares 2.0 Multi-Functional Trainer
Product Code: RPPR4000PROAR2.0
Complete with extra and upgraded attachments, plus a 16” 2-post extension, the REP PR-4000 6-Post Pro Rack is your answer to customisable, heavy-duty home or commercial strength training. This setup also includes the evolved and enhanced Ares™ 2.0 Multi-Functional Trainer, comprising dual weight stacks of 260lbs / 118kg each (upgradeable to a massive 310lbs / 140.6kg per stack), a redesigned seated row station and reoriented stacks for more space within the rack. Available in your choice of height (80” / 207.49 cm or 93” / 237.49 cm) and colour (Metallic Black or Red).
PRODUCT DESCRIPTION
Manufactured from 3x3” 11-gauge steel with a 1000lb / 454kg rackable capacity, the REP PR-4000 Rack is tough enough to handle whatever you can throw at it. It features 1” hole spacing within the bench zone and 2” spacing along the rest of the uprights, with laser-cut numbers every five holes making it easy to line up your attachments on either side. The PR-4000 is finished with robotic welding and robotic painting for a consistent, high-quality result. The PR-4000’s durability is reinforced with heavy-duty bolts, which require 2 x 24mm sockets/spanner if you’re building the rack yourself. The REP PR-4000 6-Post Pro Rack features a 2-Post extension for extra versatility, more room for attachments and enhanced stability. The kit comes equipped with Strap Safeties made from reinforced nylon that are not only a quieter option that Pin-Pipe or Flip-Down Safeties but are much gentler on your bar too.
A pair of Flat Sandwich J-Cups offer a larger landing zone than regular J-Cups and can easily handle the 454kg maximum capacity. This Pro version also features a Multi-Grip Pull-Up Bar that lets you switch up your grip and target additional muscle groups (adds an extra 1” to the height of your rack). It also comes with 3 pairs of 6” and 12” Weight Horns that can attach to the extension for convenient weight plate storage.
What sets this kit apart? The new Ares 2.0 Cable Attachment. Just like the original Ares attachment, the Ares 2.0 has been designed by REP to save serious space by combining a rack and a multi-functional trainer. The Ares 2.0 features the same dual 260lb selectorised weight stacks, rotated and pushed further back to make better use of the space inside the rack, the weight stacks can be used independently or connected for exercises that demand a heavier weight. The Ares 2.0 utilises a 2:1 cable ratio, which means 100lbs feels like 50lbs—ideal for functional training when you want a faster-travelling cable.
Alongside an integrated lat pulldown feature, the Ares 2.0 has a new seated row design that’s higher off the ground to accommodate use either on the floor or seated on a bench. It has an improved footplate design which is wider and angled at the top to provide support while sitting on a bench and adjusts for better foot positioning.
The patent-pending trolleys are easy to adjust up and down the uprights with just one hand and offer a greater range of motion that’s just like a traditional, stand-alone functional trainer. Every pulley can swivel, including the lat /seated row pulley—a feature that’s typically only seen on high-end commercial cable machines.
The Ares 2.0 attachment comes with four d-handles, a knurled lat pulldown bar, an adjustable foot plate for low rows and two integrated drop-down 5lb add-on weights. There’s an entire ecosystem of additional attachments to explore for your PR-4000, including Spotter Arms, alternative Safeties, a Landmine Attachment and much more—just select from the list of add-ons to further customise your power rack to your exact liking, The REP PR-4000 is available in your choice of height (80” / 207.49 cm or 93” / 237.49 cm) and colour (Metallic Black or Red). Please note - appearance of J-Cups may vary slightly to those in the images.
PRODUCT INFORMATION
Please select your product option(s) to see the product information.
PRODUCT INFORMATION
Please select your product option(s) to see the product information.
ADDITIONAL FEATURES
- Dimensions LxWxH: 65.35” x 74.8” x 81.2”/94.2” (166 x 190 x 207.49/237.49 cm)
- Material: 3x3” 11-gauge steel
- Hole Size: 5/8”
- Hole Spacing: 1” within bench zone, 2” elsewhere
- Included Attachments: Strap Safeties; Flat Sandwich J-Cups; Multi-Grip Pull-Up Bar; 6” and 12” Weight Horns; Ares 2.0 Cable Attachment
- Ares 2.0 Cable Attachment: 2x 260lbs / 118kg weight stacks, 2;1 pulley ratio, 3% weight plates tolerance, included accessories (4x d-handles, lat pull down bar, low row footplate, 2x integrated drop-down 5lb add-on weights)
- Base: Post-style
- Posts: 6
- Finish: Powder coated
- Height Options (without attachments): 80” / 204.39 cm or 93” / 234.39 cm
- Colour: Metallic Black or Red
- Bench Centering: Footplate has bench-centering cutouts for REP benches (AB-5000 2.0, BlackWing™ adjustable bench, AB-3000 2.0, Nighthawk™)
FREQUENTLY ASKED QUESTIONS
What are the differences between the original Ares and the Ares 2.0?
The Ares 2.0 features a higher seated row attachment point, seated row pulleys that are spaced closer together for ease of use, a larger angled footplate with bench centring cutouts, reoriented weight stacks, swivels on all pulleys, offset front trolleys, integrated drop-down micro-weight adjustments, an improved lat bar rest and improved cable routing so the trolleys can be rested at the bottom rather than the top.
What is the ratio of the Ares pulleys and the cable travel distance?
The pulleys are a 2:1 ratio, meaning 50kg feels like 25kg. The stickers on the weight stacks reflect the “feels like” weight, not the actual weight. The 93” tall option has 94.9” of cable travel, while the 80” option has 71.3” of cable travel.
Do I need to bolt this rack to the floor, even with the Ares 2.0 attachment?
We do recommend bolting REP racks to the ground.
Can I add the Lat Pulldown and Low Row to this kit?
No, unfortunately the Lat Tower cannot be added to the rack alongside the Ares 2.0 cable attachment.
What is the maximum weight capacity for the trolleys and cables?
The maximum weight capacity for both the trolley and cables is 450lbs / 204kg.
How heavy are the weight stacks?
The Ares cable attachment includes two weight stacks, with each stack weighing 260lbs / 118kg.
Can I upgrade the weight stacks?
The weight stacks can be upgraded from 118kg to 140kg.
What other accessories does this PR-4000 setup include?
The PR-4000 Pro Power Rack with Ares 2.0 is a 6-post configuration, and comes complete with a Multi-Grip Pull-Up Bar, Strap Safeties, Flat Sandwich J-Cups and Weight Horns for storing your Olympic plates. The Ares 2.0 attachment also comes with four Urethane D-Handles, a knurled Lat Pull-Down Bar, a footplate for Low Rows and two integrated 5lb weights for micro-adjustments.
