REP PR-5000 with Ares 2.0 Multi-Functional Trainer
Product Code: RPPR5000AR2.0
Evolved and enhanced, the REP Ares™ 2.0 Multi-Functional Trainer makes better use of the space within the rack. Features include dual 260lb / 118kg weight stacks for unilateral and bilateral training, a higher low row station with new footplate design, enhanced swivel functionality and more. This kit comes in a 4-post or 6-post PR-5000 configuration and is available in your choice of height (80” or 93”) and colour (Metallic Black, Red or Clear Coat).
List Price
£0.00
£3,999
From
£3,999
PRODUCT DESCRIPTION
Just like the original Ares attachment, the Ares 2.0 has been designed by REP to save serious space by combining a rack and a multi-functional trainer. The Ares 2.0 features the same dual 260lb selectorised weight stacks, rotated and pushed further back to make better use of the space inside the rack. The weight stacks can be used independently or connected for exercises that demand a heavier weight. The independent stacks allow two athletes to training simultaneously with separate resistance, or a single athlete to superset exercises off each trolley without having to change weight between each set. The Ares 2.0 utilises a 2:1 cable ratio, which means 100lbs feels like 50lbs—ideal for functional training when you want a faster-traveling cable.
Alongside an integrated lat pulldown feature, the Ares 2.0 has a new seated row design that’s higher off the ground to accommodate use either on the floor or seated on a bench. It has an improved footplate design which is wider and angled at the top to provide support while sitting on a bench and adjusts for better foot positioning.
The patent-pending trolleys are easy to adjust up and down the uprights with just one hand and offer a greater range of motion that’s just like a traditional, stand-alone functional trainer. Every pulley can swivel, including the lat /seated row pulley—a feature that’s typically only seen on high-end commercial cable machines.
The kit comes in a 4-post or 6-post PR-5000 configuration. The frame is built from heavy-duty 3x3” 11-gauge steel and boasts a 1000lb / 454kg rackable maximum weight capacity. A pair of durable Flat Sandwich J-Cups are included with the 4-post version, whereas the 6-post option adds a 1.25” Pull-Up Bar and a pair of Strap Safeties. The rack can be further customised to your exact liking with REP’s vast range of additional PR-5000 attachments—just select from the list of add-ons to really make your setup your own.
Please note, 4-post options require two pairs of PR-5000 Mini Front Foot Extensions (RPPRA5160)—one pair on the front and one pair on the back of the rack.
PRODUCT INFORMATION
Please select your product option(s) to see the product information.
PRODUCT INFORMATION
Please select your product option(s) to see the product information.
ADDITIONAL FEATURES
- Material: 3x3” 11-gauge steel
- Hole Size: 1”
- Hole Spacing: 2”
- Included Attachments: Strap Safeties (6-post only); Flat Sandwich J-Cups; 1.25” Pull-Up Bar (6-post only); Ares 2.0 Cable Attachment
- Ares 2.0 Cable Attachment: 2x 260lbs / 118kg weight stacks, 2;1 pulley ratio, 3% weight plates tolerance, included accessories (4x d-handles, lat pull down bar, low row footplate, 2x integrated drop-down 5lb add-on weights)
- Posts: 4 or 6
- Height Options (without attachments): 80” / 203.2 cm or 93” / 236.2 cm
- Dimensions LxWxH: 4-Post – 30.9” x 57.6” x 81.2”/94.2” / 78.5 x 146.3 x 207.49/237.49 cm; 6-Post – 65.35” x 57.6” x 81.2/94.2” / 166 x 146.3 x 206.2/239.3 cm
- Colour: Metallic Black, Red or Clear Coat
- Please Note: 4-post options require two pairs of PR-5000 Mini Front Foot Extensions (RPPRA5160)—one pair on the front and one pair on the back of the rack
FREQUENTLY ASKED QUESTIONS
What are the differences between the original Ares and the Ares 2.0?
The Ares 2.0 features a higher seated row attachment point, seated row pulleys that are spaced closer together for ease of use, a larger angled footplate with bench centring cutouts, reoriented weight stacks, swivels on all pulleys, offset front trolleys, integrated drop-down micro-weight adjustments, an improved lat bar rest and improved cable routing so the trolleys can be rested at the bottom rather than the top.
What are the differences between the 4-post and 6-post PR-5000 with Ares?
This standard version of the PR-5000 with Ares Multi-Functional Trainer is available in either a 4 or 6-post configuration. The 4-post option comes with a pair of Flat Sandwich J-Cups for barbell work off the front of the rack, while the 6-post has room for a pair of Strap Safeties and a 1.25” Pull-Up Bar too.
What is the ratio of the Ares pulleys and the cable travel distance?
The pulleys operate on a 2:1 ratio, meaning 50kg feels like 25kg. The stickers on the weight stacks reflect the “feels like” weight, not the actual weight. The 93” tall option has 94.9” of cable travel, while the 80” option has 71.3” of cable travel.
What is the maximum weight capacity for the trolleys and cables?
The maximum weight capacity for both the trolley and cables is 450lbs / 204kg.
How heavy are the weight stacks?
The Ares cable attachment includes two weight stacks, with each stack weighing 260lbs / 118kg.
Can I upgrade the weight stacks?
The weight stacks can be upgraded from 118kg to 140kg.
Can I add the Lat Pulldown and Low Row to this kit?
No, unfortunately the Lat Pulldown and Low Row cannot be added to the rack alongside the Ares 2.0 Multi-Functional Trainer.
What other attachment does the PR-5000 with Ares come with?
If you choose the 4-post option, a pair of Flat Sandwich J-Cups are included. If you opt for the 6-post configuration, you’ll also get a pair of Strap Safeties and a 1.25” Pull-Up Bar. The Ares 2.0 attachment also comes with four Urethane D-Handles, a knurled Lat Pull-Down Bar, a footplate for Low Rows and two integrated 5lb weights for micro-adjustments.
Do I need to bolt this rack to the floor, even with the Ares 2.0 attachment?
We do recommend bolting REP racks to the ground. The 4-post option also requires two pairs of PR-5000 Mini Front Foot Extensions (RPPRA5160)—one pair on the front and one pair on the back of the rack.
